COMPLETE SET WITH ANGLE VALVE AND M-PACT VALVE 9000
The Gibson collection gives contemporary industrial design a softer point of view. The tubular spout and handles mirror the look of exposed piping while polished edges to create a chic and Modern style.
Specification:
Application : Three Hole
Center Dimensions : 8" - 16" Center
Drain Assembly : Metal
Drain Assembly Type : Lift Rod
Red/Blue Markings : Included
Spout Reach : 5.00 "
Benefits
-Chrome finish is highly reflective for a mirror-like look that works with any decorating style
-Two-handle lever handle makes it easy to adjust the water
-Built on the Moen M-PACT common valve system, allowing you to update the faucet style in the future without replacing any plumbing
-Faucet handles can be installed between 8" to 16" for a more customized widespread installation
-Complies with Americans with Disabilities Act (ADA) specifications
-Aerated flow is ideal for everyday bathroom tasks, like brushing teeth and washing hands
-Meets EPA WaterSense® criteria to conserve water without sacrificing performance
-Limited lifetime warranty
-Includes red and blue markings
DESCRIPTION
• Metal construction with various finishes identifiable by suffix
• 1/2" IPS connections
• Hot and cold temperature indicators available
• Includes metal pop-up waste assembly
OPERATION
• Lever style handles
• Maximum handle rotation angle is 90° to full on for either handle
• Hot side counterclockwise to open (clockwise to close)
• Cold side clockwise to open (counterclockwise to close)
FLOW
• Water usage is limited to these maximum flow rates as indicated by
the corresponding product markings
° 1.2 gpm max (4.5L/min) at 60 psi
CARTRIDGE
• 1234 cartridge design
• Nonmetallic, nonferrous and stainless steel material
STANDARDS
• Third party certified to WaterSense®, ASME A112.18.1/CSA B125.1
and all applicable requirements referenced therein
• Certified to NSF 61/9 & 372
• Complies with California Proposition 65 and with the Federal Safe
Drinking Water Act
• ADA for lever handles
